Power Source | 120 V AC |
---|---|
Rated Output | 240 W |
Power Consumption | 238 W (EN60065), 520 W (AC operation at rated output) |
Frequency Response | 50 - 20,000 Hz (±3 dB) |
Distortion | 1% or less at 1 kHz, 1/3 rated power |
Input | MIC 1, 2: -60 dB*, 600 Ω, balanced, M3.5 screw terminal, distance between barriers: 8.3 mm (0.33") TEL: -10 dB*, 10 kΩ, balanced, M3.5 screw terminal, distance between barriers: 8.3 mm (0.33") AUX 1, 2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack |
Output | Speaker out: Balanced (floating), M3.5 screw terminal, distance between barriers: 8.3 mm (0.33") High impedance: 2.6 Ω (25 V), 21 Ω (70 V) Low impedance: 4 Ω (31 V) Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack |
Phantom Power | DC +21 V (MIC 1) |
S/N Ratio | 60 dB or more |
Tone Control | Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10 kHz |
Muting | MIC 1, MIC 2, and TEL have a priority function to attenuate AUX1 and AUX 2 input signals by 30 dB. (Sensitivity level for MIC 1, MIC 2, and TEL adjustable) Priority level among MIC 1, MIC 2, and TEL is the same. |
Finish | Panel: ABS resin, black Case: Steel plate, black |
Dimensions | 420 (W) × 100.9 (H) × 360.3 (D) mm (16.54" × 3.97" × 14.19") |
Weight | 15.5 kg (34.17 lb) |
