ER-1203 (10W max.) Splash-proof Hand Grip Type Megaphones

ER-1203

The ER-1203 is a compact splash-proof megaphone rated at 3 W output and features IPX5 water-jet-resistant designs. Handle and microphone with anti-bacteria treatment improve hygiene and safety during use.



QTY: Add to Request for quote Request for quote
Specification
Power Source R6P (AA) × 4 (6 V DC)
Rated Output 3 W
Maximum Output 4 W
Battery Life Approx. 8 hours (JEITA)*
Audible Range Approx. 125 m (JEITA)*
Frequency Response 500 - 6,000 Hz (SPL -20 dB)
Magnetic Circuit Neodymium magnet, inner magnet type
Diaphragm Polyimide film (voice coil, bobbin)
Anti-bacteria Treatment Mouth and handle
Water Protection IPX5
Operating Temperature -10℃ to +40℃
Finish Horn: ASA resin, clear dark gray
Other: ASA resin, dark gray
Strap: Nylon, black
Dimensions 137 (W) × 257.8 (H) × 210 (D) mm
Weight 610 g (without batteries)
Option Wall mounting bracket for megaphone: SP-1100
Note: Batteries are optional.
* JEITA: Japan electronics and information technology industries association. (EIAJ TT-4501A)
