The New N-8000SG Q2 SIP Gateway continues to allow you to connect the N-8000 intercom system to a SIP phone system and now with greater flexibility and reaching additional stations across the network.

Communication is established from the N-8000 to the SIP phone system and vice versa. The new software permits
up to 5 conversation paths at one time to reach a multitude of extensions on the N-8000 side from the N-SP80 side of the system. In return, the N-SP80 master station can call countless N-8000 series stations as well.
The ability to initiate a pages to one zone or multiple, access the door remote control features and now, be able to configure the incoming the extension number to display on master station.

Interconnection between N-8000 system and SIP system

• Easily call and transfer from N-8000 to SIP, and vice versa

Digital domain connection

• Audio conversion from N-8000 to SIP and vice versa
• N-8000 uses G.722, fs=16kHz/8kHz, 16bit; SIP uses G.711 u-law

5 speech paths at the same time

• 5 conversations with SIP and N-8000 at the same time
• 5 paging zones from SIP telephone at the same time
• e.g., 2 conversations and 3 paging zones in total at the same time

Additional functions from SIP system

• Configure SIP phone with dedicated Access Code to dial N-8000
• Paging function from SIP telephone to N-8000 system
• “Door remote control” from SIP telephone to N-8050DS, N-8640/50DS

Sipelia Supported VoIP Hardware
Cisco Certified

Comparison Chart N-8000SG Q vs N-8000SG Q2
