IP-SC15MC

IP-SC15MC Network Horn Speaker with Microphone

IP-SC15MC

 The IP-SC15MC is a network horn speaker with a microphone, which can receive broadcasts initiated by other terminals or servers and supports device configuration through a web browser. The device is also IP66 rated and can withstand temperatures as low as -45 °C, making it ideal for outdoor use. Powered by PoE/PoE+, the horn hosts audio files stored for playback, and provides an external dry-contact out for external device control. With loop fault detection function, the device can provide regular updates on its operation status.





Reset Tool        Reset Tool

Manual             Software


Firmware &
Upload Tool



QTY: Add to Request for quote Request for quote

Specifications

Power supply DC24V / 2.7A,  Removable terminal block (2 pins), PoE/PoE+ (IEEE 802.3af/at)
Power consumption 15 W (+/- 10%)
Speaker sensitivity 113dB (1W, 1m at 500 Hz to 2.5 kHz peak level)
Frequency response 250 〜10 kHz
Microphone Omni-directional electret condenser microphone
Microphone functions ANC (Ambient Noise Controller), Audio check, Audio Surveillance
with VMS software, SIP bi-directional communication
Audio sampling frequency 32kHz
Broadcasting mode -SIP Broadcasting mode: MP3, LPCM, G711A, G711U, G722, G729
-Multicast Broadcasting Mode: G711A, G711U, G722, IMA-ADPCM
-VMS Broadcasting Mode: Audio Backchannel, PCMU
-Internal Message Broadcasting Mode
Note: Each broadcast mode can be assigned an order of priority
using the Priority Setting function.
Internal messages Maximum 128MB.
Supported file formats: MP3 file, 32kHz sampling frequency, 128 kbps
Trigger: Control Input or Remote API (HTTPS)
Network I/F 100BASE-TX, MDI/MDI-X, RJ45
Network protocol TCP/IP, UDP, HTTP, RTP, ARP, ICMP, IGMP, SIP
Control input/output -2 channels inputs, no-voltage make dry contact inputs (IN1/IN2/GND),
open voltage: 5V DC, short-circuit current: 2mA or less
-1 channel output, Relay Output (COM /NO (normal open) /NC
(normal close)), withstand voltage:30V DC, control current: Max. 50mA
-Removable terminal block (6 pins: IN1/IN2/GND/NC/COM/NO)
LED Power (orange), Network Status (green)
Dust/Water protection IP66
Operating temperature -45°C~ +55°C
Operating humidity 90%RH or less (no condensation)
Finish Horn flare: Aluminum, Off-white, powder coating Reflector horn and
rear cover: ABS resin, off-white Cable Grant: Aluminum Brackets,
screws, and bolts: Stainless steel
Dimensions 285(W) x 227(H) x 277(D)m m 11.2” x 8.9” x x 8.9”
Weight 1.95kg
Accessories 6P Terminal-block (1 pcs), 2P Terminal-block (1 pcs)
